5,500 m²/h productivity with seated operation.
An 820 mm cleaning path and a 1,150 mm suction width are built for large floors. At up to 6.5 km/h, ARM 130 turns long cleaning routes into continuous, seated work.
ARM 130. Maximum output for the largest floors.
Key performance
5,500 m²/h
Productivity
130 L + 150 L
Clean and dirty water tank capacity
6.5 km/h
Working speed, seated drive
313 kg
Empty machine weight, built to industrial spec
Where ARM 130 belongs.
With up to 5,500 m²/h productivity, 280 L combined tank capacity, and 1,150 mm suction width, the ARM 130 keeps very large floors clean while the operator works comfortably from a seated position.
Applications
- Shopping-center concourses
- Warehouse aisles
- Logistics hubs
- Convention centers
- Industrial production halls
- Airport terminals
Engineered for maximum productivity across the whole shift.
Seated comfort, three-stage brush pressure, and tanks holding a combined 280 liters cut the number of stops and let the operator clean more floor without fatigue.
Three brush-pressure levels for different soil conditions.
Two 500 W brush motors deliver 155 rpm across the full 820 mm working width. Pressure of 45, 60, or 75 kg is selected by floor type and soil level — from routine maintenance to lifting stubborn industrial grime.
24 V / 200 Ah lithium-ion power system.
Lithium-ion technology eliminates the maintenance that comes with conventional batteries. No topping up, no acid spills, and no dedicated battery room — more time on the floor, less time on downtime.
130 L clean water and 150 L dirty water.
Dirty water stays isolated from clean. The extra capacity on the dirty-water side means more square meters cleaned before you stop to empty.
1,150 mm suction for dry floors in one pass.
The 600 W suction motor is sized to match ARM 130's full output across the whole shift, lifting water off the floor right behind the brushes with no need for a second pass.
Functions and intelligent capabilities
The full feature set from the Reinmatic catalog — every built-in and intelligent function ARM 130 ships with.
Functions and capabilities
- Professional seated control system
- 7" LCD display
- Intelligent control panel
- One press. Ready to work. The one-click START system activates the machine's main functions and cuts the time needed to prep before cleaning.
- LED lighting
- A built-in operator-presence sensor allows operation only when the operator is seated. This added layer of safety protects the machine, the operator, and the surroundings during everyday work.
- ARM 130 automatically adjusts driving speed through curves to hold stability, control, and operator safety. More safety when maneuvering, with no loss of productivity.
- The system automatically limits driving speed during turns to maintain machine stability and operator safety. More control when maneuvering across large floors.
- The system automatically regulates water flow to match the operating mode and travel speed. Lower water use, less waste, and a consistent cleaning result across the whole floor.
- An integrated system automatically doses cleaning solution at the right ratio. Lower chemical use, consistent cleaning quality, and fewer mistakes in operation.
- Faster maintenance. Less downtime. The quick-release brush assembly simplifies servicing and returns ARM 130 to work in just a few minutes.
- Three brush-pressure levels let you match cleaning power to the floor and the amount of soiling — from everyday maintenance to demanding industrial work.
- Front-wheel drive provides sure-footed movement, precise steering, and stable traction during operation. More machine control when maneuvering, turning, and working across large floors.
Intelligent functions
- AI-Assisted Control System — an advanced control system monitors the machine's operating parameters and helps the operator hold optimal performance, efficiency, and safety throughout the shift.
- Dynamic speed reduction — the system automatically adapts travel speed to working and maneuvering conditions. Greater stability, better control, and safer work across large floors.
- An electronic system manages the drive and power distribution so ARM 130 holds steady movement, optimal traction, and precise control in varying conditions.
- An intelligent system manages brush pressure to hold the optimal balance between cleaning power, energy use, and floor protection. The result is consistent cleaning quality across the whole floor.
- From the operator-presence sensor to automatic speed limiting through curves, ARM 130 uses advanced safety functions to keep work stable, controlled, and safe across the entire shift.
- Heavy-duty suction technology is built for intensive professional use. High suction capacity lets ARM 130 keep pace with large-floor productivity without compromising drying quality.
- The intelligent energy-management system continuously optimizes the drive, brushes, and suction. The result is longer runtime, greater efficiency, and the most out of the Lithium-ion battery.
- ARM 130 is designed around the operator. A comfortable seat, a clear control panel, and a natural driving position make hours of work possible with less fatigue and greater efficiency.
- A smart diagnostic system monitors the drive, brushes, suction, battery, and other key components. Operator and technician get timely information that reduces downtime and raises reliability.
- A professional high-output concept brings together power, runtime, ergonomics, and intelligent control systems in a machine built for the most demanding professional environments.
- ARM 130 is engineered for continuous work in demanding conditions. Intelligent control of the drive, brushes, and suction holds steady performance even at the machine's maximum load.
- Real-time intelligent control links every working system of ARM 130 into a single whole. The result is steadier operation, greater efficiency, and optimal performance in all cleaning conditions.
- The operator-presence sensor is tied into the machine's safety system. When the operator stands up, ARM 130 automatically stops the drive and working functions to ensure maximum safety on the job.
- Safety is built into every aspect of ARM 130's operation. Advanced sensors and electronic controls monitor key machine functions, raising stability, operator safety, and reliability across large floors.
- ARM 130 uses automatic diagnostics to monitor the drive, brushes, suction, battery, and electronic systems. Timely alerts enable faster intervention, less downtime, and greater machine availability.
- An advanced alert system continuously tracks machine operation and gives the operator clear information on system status, energy level, service needs, and any faults. The result is greater reliability, safety, and control across the whole shift.
- Advanced sensors analyze working conditions and floor-surface characteristics. The system automatically optimizes the brushes, drive, and other functions to ensure maximum productivity and consistent cleaning quality.
- The system recognizes changes in the structure and roughness of the floor surface and automatically adjusts the machine's operating parameters. Consistent cleaning quality with optimal traction, brush pressure, and energy use.
- A magnetic quick-release system simplifies servicing and brush changes. Less time on maintenance means more time on the floor and greater machine availability across the whole shift.
Specs by system
Technical specifications
Power
- Power source
- Battery (24 V — 200 Ah Lithium-ion)
- Battery
- 24 V — 200 Ah Lithium-ion
- Maximum runtime
- 4.5 h
- Charger
- 24 V – 30 A
Drive
- Drive motor (to wheels)
- 650 W
- Working speed
- 6.5 km/h
- Maximum gradient
- 12%
- Operator
- Ride-on, seated drive
Mechanical
- Brush motor
- 500 W × 2 (two brushes)
- Suction motor
- 600 W
- Brush rotation speed
- 155 rpm
- Brush pressure
- 45 / 60 / 70–75 kg (three-stage adjustable)
- Brush width
- 820 mm
- Cleaning / suction width
- 1,150 mm
Dimensions
- Length
- 1,622 mm
- Width
- 945 mm
- Height
- 1,336 mm
- Net weight
- 313 kg
Cleaning
- Clean water tank
- 130 L
- Dirty water tank
- 150 L
- Tank separation
- Two tanks, isolated dirty water
- Productivity
- 5,500 m²/h
Compliance
- Catalog code (TTC)
- 600406
- Class
- Ride-on floor scrubber-dryer, battery-powered
- Standards
- ISO 9001, CE, RoHS
Gallery
See the ARM 130.
ARM 130 — full control of working parameters for every floor and every task.
Brush pressure, water dosing, drive, and suction are all set to the floor type, level of soiling, and the demands of the site. It ships fully equipped: a 24 V / 200 Ah Lithium-ion battery, a 24 V / 30 A charger, two 41 cm brushes, pad holders, and a 1,150 mm LINATEX squeegee. Reinmatic offers a wide range of brushes, pads, and wear parts matched to different floor types.
Request the accessory list →- Battery
- Charger
- Brushes
- Pads
- Squeegee rubber
Configure your ARM 130.
Tell us the floor area, the surface type, and your shift schedule. We'll put together a machine recommendation, the right configuration, and an accessory set matched to your site.
